Media Type:
Label/Tag Roll

Width Range:
19 mm (0.8 in) to 112 mm (4.4 in)

Thickness Range:
0.06 mm (0.003 in) to 0.25 mm (0.01 in)

Winding:
Wound in or out

Ribbon:
Maximum outside diameter: 65 mm (2.6 in) Core diameters: 13 mm (0.5 in) or 25 mm (1 in) - requires provided adaptors M inimum core widths: 109 mm (4.3 in) for 0.5 in diameter or 25 mm (1 in) for 1 in
diameter M aximum core width: 109 mm (4.3 in) Width range: 25 mm (1 in) to 109 mm (4.3 in) Winding: coated-side-in or coated-side-out

Index Sensor Range:
Transmissive (top and bottom sensor combination): gap, hole or notch: Basic: 5 mm (0.2 in) right of CL A dv/Pro: 42 mm (1.7 in) left of CL to 34 mm (1.3 in) right of CL Reflective (bottom sensor only) bar, hole or
notch: Basic: 5 mm (0.2 in) right of CL, A dv/Pro: 58 mm (2.3 in) left of CL to 34 mm (1.33 in) right of CL For optimum print quality and printer performance, use certified Honeywell media supplies

Communication Ports (Standard):
Serial RS232, USB 2.0, Parallel Bi-directional, 10/100 BaseT Ethernet, USB Host

Communication Ports (Optional):
802.11 a/b/g, Bluetooth® v2.0

802.11 a/b/g:
Network standard: IEEE 802.11 a/b/g; wireless access modes: infrastructureand ad-hoc

Network Support:
DHCP, TCP/IP, UDP, DNS, BOOTP

Standard Printer Warranty(When used with approved supplies):
1 year (including platen roller and installed options)

Standard Printhead Warranty(When used with approved supplies):
1 year or 25,400,000 mm (1,000,000 in), whichever comes first

Extended Warranty:
Contact your Honeywell sales representative for extended warranty options available through Honeywell Repair Services
